MaxWool 2300 High Temperature

MaxWool® 2300

Refractory Ceramic Fiber Blankets

MaxWool 2300 high-temperature insulating blankets are made from long strand spun, high purity ceramic fibers forming a strong, flexible needled product which provides superior insulation properties for usage at higher temperatures.

The strong needling of MaxWool ceramic blankets derive in a completely inorganic product with no binder resulting in smoke or flame.

MaxWool 2300 is rated to 2300°F (1260°C) and is available in a range of thicknesses and densities.

Physical Properties

  • Maximum Use Temperature

    2300⁰F (1260⁰C)

  • Continuous Use Temperature

    2150°F (1177°C)

  • Chemistry

    Alumina, Silica

  • Composition

    RCF (Refractory Ceramic Fiber)

  • Shrinkage @ 2400°F / 24 hrs

    0-3%

  • Average Fiber Diameter

    3-4 Microns

Key Features

  • Low Thermal Conductivity
  • Low Heat Storage
  • High Tensile Strength
  • Thermal Shock Resistance
  • Sound Absorption
  • Easy to Install
  • Contains no Binder
  • Contains no Asbestos
  • No Curing on Dry Out Time Required

Related Industries

NUTEC_Oil_Gas-Industry

Oil & Gas

High-temperature insulation and passive fire protection products and systems to provide effective thermal management, improve processes and maintain efficiency.

NUTEC_Steel-Industry

Steel

Sealing, insulating and cover products designed to withstand elevated temperatures in tough operating conditions.

NUTEC_Aluminum-Industry

Aluminum

First-rate thermal management solutions for many heat treat processes, optimizing heat-up/cool-down cycles.

NUTEC_Power_Generation-Industry

Power Generation

Innovative insulation products for power generation applications such as boilers, turbines, pipe insulation, among others.

NUTEC_Ceramics_Glass-Industry

Ceramics & Glass

High-temperature products and systems for thermal insulation in ceramics and glass manufacturing.

Common Applications

  • Reformer and Pyrolysis Furnaces
  • Tube Seals, Gaskets and Expansion Joints
  • High-Temperature Pipe, Duct and Turbine Insulation
  • Crude Oil Heater Linings
  • Heat Treating and Annealing Furnaces
  • Furnace Door Linings and Seals
  • Soaking Pit Convers and Seals
  • Furnace Hot Face Repairs
  • Reheat Furnaces
  • Ladle Covers
  • Boiler Insulation
  • Boiler Doors
  • Reusable Turbine Covers
  • Pipe Covering
  • Kiln Car Insulation and Seals
  • Continuous and Batch Kilns
  • Insulation of Commercial Dryers and Covers
  • Veneer Over Existing Refractory
  • Stress Relieving Furnaces
  • Glass Furnace Crown Insulation
  • Fire Protection
